BMX Race Frame Size Guide – What Size BMX Frame Do I Need?

Choosing the right BMX race frame size can make a huge difference to how a bike feels on the track.

We get asked about frame sizing all the time, particularly when a rider is growing, moving between sizes or looking at a different brand of frame.

While rider height gives us a really good starting point, BMX sizing isn't an exact science. Two riders can be exactly the same height and still feel more comfortable on different size frames.

So we've put together this guide to make choosing your BMX race frame a little easier.

BMX Race Frame Sizing Chart

A quick note on sizing

You'll notice there is quite a bit of overlap between the height ranges.

That's intentional.

The chart is designed to be a starting point, rather than a rule that says a rider of a certain height must ride a particular size.

Rider proportions, strength, experience, riding style and personal preference all play a part in getting the right fit.

What Does BMX Frame Size Actually Mean?

With a BMX race frame, the measurement we pay the most attention to is the top tube length.

The top tube is measured from the centre of the head tube to the centre of the seat tube and is generally shown in inches.

As the frame size increases, the top tube gets longer and gives the rider more room on the bike.

As a rough example:

• Junior – around 18.5"

• Expert – around 19.5"

• Pro – around 20.5"

• Pro XL – around 21.25"

• Pro XXL – around 21.5"–21.75"

• Pro XXXL / 4XL – 22"+

This is why we recommend looking at the actual top tube measurement, rather than relying solely on whether a frame is called Expert, Pro, Pro XL and so on.

Why Do Different BMX Brands Have Different Size Names?

This is where BMX sizing can become a little confusing.

Most manufacturers use the traditional size names such as Mini, Junior, Expert, Pro and Pro XL, but you'll also see additional sizes depending on the brand.

These can include:

• Junior Plus

• Junior XL

• Expert XXL

• Pro Plus

• Pro L

• Pro XXL

• Pro XXXL

• Pro XXXXL

These extra sizes simply give riders more options between the traditional frame sizes.

For example, a rider might feel cramped on a Pro but not quite be ready for the extra length of a Pro XL. A Pro L or Pro Plus can fill that gap nicely.

The name on the frame isn't the most important measurement — the top tube length is.

What If You're Between Two Frame Sizes?

This is probably the most common sizing question we get.

If you fall into the overlap between two frame sizes, both may technically work.

The decision then comes down to the rider.

A slightly smaller frame can suit a rider who:

• Likes a responsive bike.

• Is still developing their bike handling.

• Wants the bike to be easier to manual and move around.

• Is younger or lighter for their height.

• Is only just entering the height range for the next size.

A slightly larger frame can suit a rider who:

• Is strong and confident on the bike.

• Wants more stability at speed.

• Wants more room when sprinting.

• Is already near the top of their current frame size.

• Prefers a longer, more planted feeling bike.

There isn't necessarily a wrong answer when you're sitting between two sizes.

Sometimes it comes down to what the rider is used to and how they like their bike to feel.

Should I Buy a Bigger BMX Frame for My Child to Grow Into?

A little bit of growing room is fine.

Buying a frame that is considerably too big isn't something we'd recommend.

It can be tempting, especially when kids seem to grow overnight, but an oversized BMX can be harder for a young rider to control.

That can affect their:

• Gate starts

• Manuals

• Pumping

• Jumping

• Cornering

• Confidence on the bike

For developing riders, we'd rather see them confidently riding a bike that fits them now than struggling with a bike they'll eventually grow into.

Should BMX Frame Size Be Based on Age or Height?

We recommend using height rather than age.

Age can give a very rough indication, but two 10-year-olds can be completely different heights and builds.

Height gives us a much better starting point.

From there we can look at the rider's current bike, experience, body proportions and how much growing room they actually need.

Don't Forget the Rest of the BMX Setup

The frame is only one part of getting a BMX race bike to fit properly.

Other components make a big difference too, including:

• Handlebar rise

• Stem length

• Crank length

• Bar position

• Saddle position

• Wheel size

Sometimes a rider who feels cramped doesn't immediately need a bigger frame.

A change in bar rise or stem length can sometimes give them the extra room they need.

On the other hand, if you're having to fit very tall bars and a long stem just to make a small frame comfortable, that's usually a good indication it's time to look at moving up a frame size.

Micro Mini Frames and Wheel Size

One thing worth mentioning is that the smallest Micro Mini race setups can use an 18-inch wheel, even though the majority of BMX race bikes from Mini upwards use 20-inch wheels.

So if you're putting together a bike for a very small rider, don't just look at the frame size — wheel size and the complete setup are important as well.

Our Best Advice?

Use the sizing chart as your starting point, but don't get too caught up in making a rider fit neatly into one box.

The best BMX setup is the one the rider feels comfortable, balanced and confident on.

If you're unsure between two sizes, or you're looking at changing brands, get in touch with us.

Send us:

• Rider height

• Current frame and top tube length

• Current frame brand

• Age or race class

• How long they've been racing

• What they're finding uncomfortable about their current bike

From there we can help narrow down the best options.

At Trackstars BMX, we work with BMX race bikes and components every day and stock frames across a wide range of sizes from brands including Supercross, Syndyt, Speedco and more.

If you're not sure, ask us before you buy — we're always happy to help get the setup right.
